Description

PowerBar 14HF is an IP65 rated multi-functional wash linear fixture for indoor or outdoor use. It features 14x 40W LEDs (RGBW), 14 individually controlled sections with Control and a 25-degree beam angle and diffuser . With an all metal, black housing and IP65 outdoor rating, its protected from elements - dust, sand, moisture and liquids.

Features:

IP65 rated – protects from dust, sand, moisture and liquid (Temporary outdoor use only)
All metal construction, 14x40w,RGBW,High power pixel control, with diffuser for soft wash
Flicker free for film and broadcast, Smoothly dimming
with omega stander, wireless 2.4G is for optional
The bar is link-able to create unlimited washer/pixel bar.
Modular structure for easy maintenance



Light Source:

• LED: 14x 40W RGBW LEDs (50,000 hr.), Pixel control,With diffuser
• Beam Angle: 25-degrees, diffuser for soft wash, pixel bar.


Construction:

Display: OLED display with function buttons
Data In/Out: Seetronic IP65 rated, 5-pin DMX In/Out (Ture 1), Artnet date in-out for option.
Wireless 2.4G for optional.
Power In/Out: Seetronic Ture 1
All Metal Heavy-Duty Housing: Built To Last In Outdoor or Touring Applications
Modular structure for easy maintenance


Control:
• DMX channel modes:4chs/10chs/62chs
• Built-in internal programs, Pixel bar,
• 14 individually controlled sections with Zone Control
• 0-100% Dimming + smooth 16-bit Dimming
• 16 bit Dimming Curve Modes• Control Mode: DMX512, RDM (Remote Device Management)
• With Wired Digital Communication Network, RDM

Electrical:
• Power voltage: AC100-240V, 50/60Hz (Multi-voltage)
• Power consumption: 700W max

Dimensions & Weight:
• Dimension (LxWxH): 39.4” x 7.2” x 3.7” / 100x181x93mm
• Weight: 20.9 lbs. / 9.5 kg.

ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
